AT THE CENTRE OF LONDON'S FINANCIAL DISTRICT STANDS THE BANKING HALL, 8—10 MOORGATE, JUST 65 METRES FROM THE BANK OF ENGLAND.

IT WILL OFFER 135,000 SQ FT OF PREMIUM OFFICE ACCOMMODATION.

Terrace views to the Bank of England
3,500 sq ft reception
Looking North
The Banking Hall at 8-10 Moorgate
Skyline view at dusk
SUMMARY SPECIFICATION
KEY DIMENSIONS
  • 1.5m planning grid
  • 2.75m floor to ceiling
FLOORS AND CEILINGS
  • 150mm (nominal) raised access floor
  • 750 x 750mm powder-coated perforated metal pan ceiling tiles
AIR CONDITIONING
  • EC/DC 4-pipe variable fan coil on the perimeter providing heating and cooling with a 2-pipe variable speed fan coil in the internal areas to provide cooling only
  • OFFICES: SUMMER
    24.5°C db ±1.5°C office average target internal operative temperatures 21.0°C db ±1.5°C air temperature
  • OFFICES: WINTER
    22.0°C db ±1.5°C office average target internal operative temperatures
  • OUTSIDE AIR SUPPLY
    12l/s per person (FCU fit out) based on 8m/person. Equal to 1.5l/s/sq m of the net office area
  • TOILET EXTRACT
    10 air changes per hour extract (min) per cubicle with air supply by transfer from offices

ELECTRICAL SERVICES
  • Small power 25W/sq m plus additional 18W/sq m capacity in the riser
  • Office lighting: an average of 300–500 lux at working plane
  • BMS system is provided to control the landlord's and Cat A building services within the building. The system is capable of a 20% extension by the tenant
  • CCTV: A CCTV system, linked to the office reception and building manager's office to monitor the service entrance and all entrances/exits
POWER
  • A new 11kV UKPN HV switchroom will be provided at basement level. This will feed two packaged substations. Rising bus-bar mains utilising plug-in tap-off units will serve each floor for tenants fit-out of distribution boards
  • A separate UKPN substation will be provided at basement level providing a back-up life safety supply for the office systems
  • Space for a tenant generator (up to 2MVA) located on roof to enable 100% back up of whole building

CHP
  • In order to meet the energy efficiency and sustainability requirements of the building a CHP unit is located within the basement
POPULATION DENSITY
  • Occupation density 1 person per 8 sq m
  • Means of escape 1 person per 6 sq m
LIFTS
  • 4 number 21 person destination controlled passenger lifts
  • 1 number goods lift (2000 kg)
WC AND SHOWER PROVISION
  • 60/60 male female (BS 2006 and 2009)
  • 20 showers in basement
BLINDS AND FLOOR BOXES
  • Blinds provided on external windows
  • Floor boxes provided at 1 per 10 sq m
BICYCLE STORAGE PROVISION
  • 78 bicycle spaces and lockers located in basement
TERRACES
  • 4 fully accessible external terraces
SUSTAINABILITY
  • BREEAM 2011 – Target excellent
 FLOOROFFICETERRACE
SQ MSQ FTSQ MSQ FT
 NET OFFICE
 (EXCL. RECEPTION)
12,109130,340
 RETAIL GROUND84905
 BASEMENT38410
 TOTAL12,562135,220
    PLANS ARE NOT TO SCALE AND FOR IDENTIFICATION PURPOSES ONLY
900 SQ M
9,685 SQ FT
1,432 SQ M
15,415 SQ FT
1,716 SQ M
18,470 SQ FT
1,716 SQ M
18,470 SQ FT
1,666 SQ M
17,935 SQ FT

TERRACE
10 SQ M
108 SQ FT

1,493 SQ M
16,070 SQ FT

TERRACE
64 SQ M
689 SQ FT

1,354 SQ M
14,575 SQ FT
916 SQ M
9,860 SQ FT

TERRACE
260 SQ M
2,800 SQ FT

916 SQ M
9,860 SQ FT
SECOND FLOOR
CORPORATE OPEN PLAN–
MULTI-FLOOR TENANT
Single cellular offices8
Open plan workstations204
Total headcount212
Indicative Planning Ratio per personSQ M / 86 SQ FT
SECOND FLOOR
LEGAL OCCUPIER–
SINGLE-FLOOR TENANT
Single partner offices8
Double associate offices38
Total fee earners47
Secretary15
Business support12
Receptionist2
Total headcount78
Indicative Planning Ratio per fee earner36 SQ M / 387 SQ FT
Indicative Planning Ratio per person22 SQ M / 236 SQ FT
SIXTH FLOOR
CORPORATE OPEN PLAN–
MULTI-FLOOR TENANT
Single cellular offices19
Open plan workstations116
Total headcount135
Indicative Planning Ratio per person10 SQ M / 107 SQ FT
SEVENTH FLOOR
CLIENT MEETING SUITE
1 x 20 Person meeting room20
1 x 15 Person meeting room15
2 x 14 Person meeting room28
1 x 12 Person meeting room12
1 x 10 Person meeting room10
2 x 6 Person meeting room12
3 x 6 Person dining room18
2 x Multifunction rooms44
1 x 20 Person multifunction rooms20
1 x 24 Person multifunction rooms24
2 x Phone booth2
1 x Visitor offices1
EIGHTH FLOOR
EXECUTIVE FLOOR
16 Person board room1
Business lounge1
Executive offices6
PA workstations6
Support/admin workstations8
Visitor offices2
Total headcount22
BASEMENT
BICYCLE STORAGE AND CHANGING
Bicycle lockers78
Female showers12
Male showers8
